P320HVN02.0 Ekran için LVDS Kablo Düzeneği
Custom LVDS Cable Assembly For P320HVN02.0 Display with
JAE & DF13
LVDS Cable Assembly For P320HVN02.0 Display:
This custom LVDS cable assembly is specifically designed for the P320HVN02.0 TFT LCD
panel, featuring a JAE F1-RE51HL connector on the panel side and a DF13-30DS-1.25
connector on the controller side.
The cable uses AWG 28 shielded wires, including 10 twisted differential pairs and 10 straight
signal wires, ensuring excellent signal integrity for high-speed LVDS transmission.
All assemblies are manufactured according to IPC/WHMA-A-620 Class 2 standards and are
100% electrically tested before shipment.
OEM and ODM customization is fully supported.
Key Features Of LVDS Cable Assembly For P320HVN02.0 Display:
Designed for P320HVN02.0 LVDS interface
JAE F1-RE51HL panel connector
DF13-30DS-1.25 controller connector
10 twisted pairs + 10 straight wires (30 wires total)
Shielded cable with ground terminal
Stable differential signal transmission
High EMI resistance
AWG 28 wire gauge
Custom pin assignment supported
RoHS compliant
Typical Applications Of LVDS Cable Assembly For P320HVN02.0 Display:
TFT LCD display modules
Industrial HMI systems
Medical display equipment
Embedded control systems
Industrial PCs & monitors
Technical Specifications Of LVDS Cable Assembly For P320HVN02.0 Display:
| Item | Specification |
|---|---|
| Product Type | LVDS Cable Assembly |
| LCD Panel Model | P320HVN02.0 |
| Panel-side Connector | JAE F1-RE51HL |
| Controller-side Connector | DF13-30DS-1.25 |
| Cable Type | Shielded LVDS cable |
| Wire Gauge | AWG 28 |
| Total Wires | 30 |
| Differential Pairs | 10 twisted pairs |
| Straight Wires | 10 |
| Signal Type | LVDS |
| Cable Length | 980 mm |
| Grounding | Shield + GND terminal |
| Power Lines | 4 × LCD VCC |
| Manufacturing Standard | IPC/WHMA-A-620 Class 2 |
| Compliance | RoHS |
| Customization | Supported |
Customization Capability Of LVDS Cable Assembly For P320HVN02.0 Display:
We offer full LVDS cable customization, including:
Cable length adjustment
Alternative LCD panel models
Connector replacement
Pin mapping & signal definition
Shielding structure optimization
Engineering drawing review is supported before mass production.
Quality Control Of LVDS Cable Assembly For P320HVN02.0 Display:
100% continuity & short test
Differential pair impedance inspection
Visual & crimp inspection
Shield grounding verification
Batch traceability control
